Adding LISTEN WHISPER BARGE to FREEPBX ASTERISK

Adding LISTEN, WHISPER, and BARGE to FREEPBX ASTERISK

Adding LISTEN, WHISPER, and BARGE to FREEPBX or ASTERISK. If you are running on FreePBX or Asterisk, most likely you will want the ability to listen in on agents calls, also known as joining multiple calls, or connected two calls to a manager, or other variations of barging in on a bridged channel.

For the purpose of this article, we will define manager as the caller who is the spying channel, agent who is the spied-on channel, and client who is the bridged channel / 3rd party. We define listen, whisper, and barge as follows:

Listen

Monitor an agents call. The manager can hear both the agent and client channels, but no-one can hear the manager.

Whisper

Whisper to the agent. The manager can hear both the agent and client channels, and the agent can also hear the manager, but the client can only hear the agent, hence “whisper.”

Barge

Barge in on both channels. The manager channel is joined onto the agent and client channels, and all parties can hear each other. Be warned, if the original agent leaves the call, the call is dropped. This is not a 3-way call.
(However you can barge in, and when comfortable, initiate a 3way call to your extension so you can continue the call without the agent. This procedure varies from client to client (soft/hard phones))

One more note: We can also provide 3-way calling [live transfer] services on the server side, however this is outside the scope of this document. Please contact us for details.

Enough chit-chat, let’s get to the dialplan!

Note: In newer versions of FreePBX, custom includes are disabled by default.
This means that the new “ext-local-custom” context’s that we are about to create won’t be imported into the PBX “Brain”. To fix this, go to :
Settings->Advanced Settings
Find the “Dialplan and Operational” section, and change Disable -custom Context Includes? to False.
Be sure to click on the little checkbox that appears to the right to save the setting, then Apply Settings to rebuild the files. This is required or else the ext-local-custom context that we add won’t be included into the engine.

This should be placed in /etc/asterisk/extensions_custom.conf for FreePBX
[ext-local-custom]

;listen
exten => _*222x.#,1,Macro(user-callerid,)
exten => _*222x.#,n,Answer
exten => _*222x.#,n,NoCDR
exten => _*222x.#,n,Wait(1)
exten => _*222x.#,n,ChanSpy(sip/${EXTEN:4},q)
exten => _*222x.#,n,Hangup

;whisper
exten => _*223x.#,1,Macro(user-callerid,)
exten => _*223x.#,n,Answer
exten => _*223x.#,n,NoCDR
exten => _*223x.#,n,Wait(1)
exten => _*223x.#,n,ChanSpy(sip/${EXTEN:4},qw)
exten => _*223x.#,n,Hangup

;barge
exten => _*224x.#,1,Macro(user-callerid,)
exten => _*224x.#,n,Answer
exten => _*224x.#,n,NoCDR
exten => _*224x.#,n,Wait(1)
exten => _*224x.#,n,ChanSpy(SIP/${EXTEN:4},qB)
exten => _*224x.#,n,Hangup
